D-subminiature
Connectors
Information
Introduction
Printed Circuit Board
Layout Hole Dimensions
Standard Density D-subminiature
Mounting Dimensions Board Layouts
Footprints (Component side shown)
9 Position
Shell Size E
25X
4
25 Position
Shell Size B
15X
15 Position
Shell Size A
The footprints on this page are standard for all metal
PC Board Lead Hole Size
shell D-subminiature connectors.
Terminal Dia. Hole
Dia.
in mm
in
mm
On all right-angle D-subminiature connectors, the
short row of contacts is positioned closest to the
edge of the board.
Call Toll Free: 1 (800) 323-9612
4-8
.040 1.02
.030 0.76
.024-.025 0.61-0.64
.055
.045
.039
1.40
1.14
0.99
